Rolling Stock AI System with Intel® Core™ Processors (11th Gen) and NVIDIA Quadro MXM GPU, compliant with EN 50155 Advantech ITA-580G
Price and avalability
| Partnumber | Description | Price VAT incl | Avalability |
|---|---|---|---|
| ITA-580G-W7A2 | ITA-580G,i7-11850HE,16G RAM,w/MXM,24V-110Vdc | 354 573,0 |
ITA-580G powered by Intel's 11th Gen. processors and compatible with NVIDIA's Quadro MXM GPU series, delivers a robust solution for AI applications in the rail industry. This computer excels in tasks like accelerated rendering, AI inference, real-time video analysis, and overall computing performance. Designed for rail applications, it seamlessly integrates 2 x DisplayPort interfaces, complemented by 4 additional interfaces from the MXM GPU module. The system also features 3 x 2.5 GbE ports in M12 X-Coded format, wide input support from 24V to 110VDC, TPM 2.0 security, and 2 removable trays for 2.5-inch SSDs. Adheres to the rigorous standards set forth by EN 50155, EN 50121-3-2, EN 50121-4, and EN 45545-2 test criteria. This compliance guarantees unwavering stability and reliability in the execution of critical applications within railway environments. As a result, the ITA-580G emerges as an optimal solution for AI inference needs within rolling stock applications.
- 11th Gen Intel® Core™ H-Series platform with RM590E
- Fanless MXM GPU design and support NVIDIA Quadro MXM 3.1 Type A/B form factor GPU module
- Real-time graphic analysis catering to AI Applications
- With an MXM GPU module conforming to EN 50155 and EN 50121-3-2/EN 50121-4 standards
- SKY-MXM modules provide product life support extending beyond 5 Years
- Wide range 24 - 110VDC power input, compliant with EN 50155
- No RED certification
Additional information
System Chipset |
|
| CPU | i7-11850HE |
| Base frequency/Turbo Boost | 2.6/4.7GHz |
| L3 Cache | 24M |
| Cores/Threads | 8 P-core/16T |
| Chipset | RM590E |
| BIOS | AMI UEFI 256Mbit |
Memory |
|
| Technology | Dual channel DDR4 3200 MHz |
| SO-DIMM slot | 1 |
| On-board RAM | 16GB |
| Max. Capacity | Up to 32GB |
Security |
|
| TPM | TPM 2.0 |
Graphics |
|
| Chipset | Intel® UHD Graphics for 11th Gen Intel® Processors |
| Max. Frequency | 1.35 GHz |
I/O |
|
| USB |
|
| Serial Port | 2 x DB9, RS-232/422/485 with 2KV Isolation, supports auto-flow control |
| DIO | 1 x DB9, 4-bit DI/ 4-bit DO with 2KV Isolation |
| Display | 2 x DP port (max resolution up to 4096 x 2304 at 60 Hz), 4 x DP port from MXM (Discrete Mode) |
| Audio | 1 x DB9, 1 x Line-out, 1 x Mic-in |
Ethernet |
|
| Controller | Intel 3 x i226-IT (Industrial-grade) |
| Transmission Speed | 10/100/1000/2500 Mbps |
| Connector | 3 x M12 X-Coded(F) |
Storage |
|
| SSD easy-swap tray | 2 x 2.5" 7mm SSD, Support RAID 0/1/5/10 |
| mSATA | 1 x mSATA slot |
Others |
|
| Mini PCIe | 2 x Mini PCIe Socket (Full size) |
| M.2 | 2 x M.2 3042/3052 B+M Key / 1 x M.2 2230 A+E Key |
| PCIe | 1 x PCIex16 thru. MCIO connector |
| SIM card | 4 x micro SIM slot, each M.2 slot supports dual micro SIM cards |
LED & Button |
|
| LED | 1 x power, 1 x storage, 1 x battery, 1 x CPU temperature alert |
| Button | 1 x Power on / off switch |
Power |
|
| Input Voltage | 24 - 110VDC power input, compliant with EN 50155 |
| Connector | 1 x M12 K-Coded (M) 5 pin |
| Ignition | Enable range from 10 to 30VDC with 2.5KV isolation |
Watchdog Timer |
|
| Output | System reset |
| Interval | Programmable 1~255 sec/min |
Environment |
|
| Temperature |
|
| Humidity | 5% ~ 95% @ 40 °C (Non-Condensing) |
Mechanical |
|
| Dimension (W x H x D) |
|
| Install | Desktop mounted using a mounting bracket |
| Ingress Protection | IP40 rating |
Software |
|
| Operating System | Windows 10, 11, Linux |
Certification |
|
| EMC | CE/FCC Class A, CCC |
| Safety | UL, CB, CCC, BSMI |
EN 50155 Compliance |
|
| Operating temperature classes | EN 50155:2021 OT4 (-40 ~ 70 °C); With 60-watt of MXM module: EN 50155:2021 OT1 (-25 ~ 55°C) |
| Shock and Vibration | IEC 61373 body mount class B |
| Interruptions of Voltage Supply | Class S2: 10 ms interruptions |
| Supply Change Over | Class C1: at 0.6 Un during 100 ms without interruptions |
| EMC | EN 50121-3-2/EN 50121-4 |
| Fire protection | EN45545-2:2020 HL3 |
