Fanless AI Inference System (Lite) Based on NVIDIA® Jetson™ TX2 NX Advantech MIC-710AILT

Price and avalability

Partnumber Description Price VAT incl Avalability
MIC-710AILT-00B1 Система штучного інтелекту Advantech MIC-710AILT(полегшена версія) на базі NVIDIA Jetson TX2NX Lite AI Inference System  46 796,4
MIC-710AILT-00B2 NVIDIA Jetson TX2NX Lite AI System_NO SD  46 796,4
  • Fanless and ultra-compact design
  • Embedded with NVIDIA® Jetson™ TX2 NX up to 1.1.33 TFLOPs
  • Supports 1 x GbE, 1 x USB 3.2 Gen 1 (5 Gbit/s)
  • Supports 1 x mPCIe, 1 x M.2 2280
  • Supports Allxon 24/7 remote monitoring and OTA deployment

Additional information

Processor

CPU Dual-core NVIDIA Denver 2 64-bit CPU and quad-core ARM A57 Complex
GPU NVIDIA Pascal™ Architecture GPU with 256 CUDA cores
Memory 4GB LPDDR4
Flash 16G of eMMC

I/O

Ethernet 1 x 10/100/1000 Mbps
Display HDMI (Max. resolution 3840x2160 @ 60Hz)
USB
  • External: 1 x USB 2.0, 1 x USB 3.2 Gen 1
  • Internal: 1 x USB 2.0 (by pin header)
OTG USB 1 x Micro USB

Expansion

Mini PCIe 1 x mPCIe (Signal: PCIe x1 + USB 2.0)
SIM 1 x Nano SIM slots

Storage

M.2 1 x M.2 2280 (M-Key, NVMe, Signal: PCIe x4)
SD Card 1 x Micro SD

Power

Mode Therminal block, 2-pin, AT
Voltage 12 ~ 24 VDC

Environment

Operating Temperature* -10 ~ 60 °C with 0.7 m/s air flow
Operating Humidity 95% @ 40 °C (non-condensing)
Vibration 3 Grms @ 5 ~ 500 Hz, random, 1 hr/axis
Shock 10G / 11ms

Mechanical

Dimensions (W x D x H) 85 x 118 x 45 mm (3.3" x 4.6" x 1.8")
Weight 1.2 kg (2.65 lb)
Installation Desktop / Wall mount / DIN-rail

BSP

Jetpack 4.6
Certifications CB/UL/CE/FCC/BSMI/CCC (No RED certification)
