AI Inference System Advantech MIC-711-OX

AI Inference System Based on NVIDIA Jetson Orin NX Advantech MIC-711-OX

Price and avalability

Partnumber	Description	Price VAT incl	Avalability
MIC-711-OX4A1	NVIDIA Jetson Orin NX 16G Lite AI System	111 324,0
MIC-711-OX3A1	NVIDIA Jetson Orin NX 8G Lite AI System	81 473,4

• Fanless and ultra-compact design
• Embedded with NVIDIA® Jetson Orin™ NX up to 100 TOPS
• Supports 1 x GbE, 2 x USB 3.2 Gen1 (5 Gbit/s)
• Supports 1 x mPCIe, 1 x M.2 3052, 1 x M.2 2280
• Supports Allxon 24/7 remote monitoring and OTA deployment

Additional information

Processor System
CPU	16GB: 8-core NVIDIA Arm® Cortex A78AE v8.2 64-bit CPU (2MB L2 + 4MB L3) 8GB: 6-core NVIDIA Arm® Cortex A78AE v8.2 64-bit CPU (1.5MB L2 + 4MB L3)
GPU	1024-core NVIDIA Ampere GPU with 32 Tensor Cores
Memory	16GB: 16GB LPDDR5 8GB: 8GB LPDDR5
Flash	-
I/O
Ethernet	1 x 10/100/1000 Mbps
Display	HDMI (Max. resolution 3840x2160 @ 60Hz)
USB	External: 2 x USB 3.2 Gen 1, 1 x USB 2.0 Internal: 1 x USB 2.0 (by pin header)
OTG USB	1 x Micro USB
Expansion
Mini PCIe	1 x mPCIe (Signal: PCIe + USB 2.0)
M.2	1 x M.2 3052 (B-Key, Signal: USB)
SIM	2 x Nano SIM slots
Storage
M.2	1 x M.2 2280 (M-Key, NVMe, Signal: PCIe x4)
SD Card	1 x Micro SD
Power
Mode	Terminal block, 2-pin, AT
Input Voltage	9 ~ 36 VDC
Environment
Operating Temperature*	-10 ~ 60 °C with 0.7 m/s air flow
Operating Humidity	95% @ 40 °C (non-condensing)
Vibration	3 Grms @ 5 ~ 500 Hz, random, 1 hr/axis
Shock	10G / 11ms
Mechanical
Dimensions (W x D x H)	130 x 130 x 46 mm (5.1" x 5.1" x 1.8")
Weight	1.2 kg (2.65 lb)
Installation	Desktop / Wall mount
BSP
Jetpack	Above 5.1
Certifications	CB/UL/CE/FCC/BSMI/CCC (No RED certification)
