DP
Extended T range
HDMI
IP66
Resistive Touch
Screen Size 19"
VGA
Wallmount
19" SXGA Industrial Monitors with Resistive Touch Control, Direct HDMI, DP, and VGA Ports Advantech FPM-719
Price and avalability
| Partnumber | Description | Price VAT incl | Avalability |
|---|---|---|---|
| FPM-719-R9AE | Промисловий дисплей Advantech FPM-719 19" SXGA Ind. Monitor,w/Resistive TS(24Vdc) | 69 198,9 |
In IIoT and Industry 4.0, more and more customers need data to be visualized to help process management and decision making. The FPM-700 series comprises 15", 17" and 19" industrial-grade monitors with sleek, simple lines and a true-flat touchscreen. Equipped with durable 5-wire resistive touchscreen and an IP66-rated front bezel, FPM-700 series is specifically designed for industrial applications. Moreover, FPM-700 series support a wide operating temperature range (-20 ~ 60 °C/-4 ~ 140 °F) and various mount options to make these monitors ideal for factory and machine automation display applications.
- 19" SXGA TFT LED LCD with 70,000 backlight lifetime
- Direct HDMI, DP and VGA input interfaces
- Anti-glare screen with tempered glass
- Robust system with Die-casting aluminum chassis and IP66-rated aluminum alloy front bezel
- Lockable I/O connectors
- Slim design enables easy installation
- OSD control buttons with 2 user-defined contrast/brightness controls
- Combo RS-232 & USB interface for touchscreen functionality
- Supports various mount options: panel, wall, desktop, rack or VESA arm mounting
Additional information
General |
|
| Certification | BSMI, CCC, CE, FCC Class A, UL |
| Dimensions (W x H x D) | 454 x 379.8 x 48.5 mm (17.87 x 14.9 x 1.9 in) |
| Enclosure | Front panel: Die cast magnesium alloy Rear cover: Die-casting aluminum |
| Mount Options | Stand, Wall, Panel and VESA arm (75 x 75mm) |
| Power Input | Terminal Block: 24 VDC input |
| Video Port | HDMI, DP, and VGA |
| USB | Rear I/O USB 2.0 type A |
| Weight (Net) | 6.2 kg |
Power Consumption |
|
| FPM-719-R9AE | 1.04 (Standby), 15.44 (Max) |
LCD Display |
|
| Display Type | SXGA TFT LCD |
| Display Size | 19" |
| Max. Resolution | 1280 x 1024 |
| Max. Color | 16.7M |
| Viewing Angle (H/V °) | 170/160 |
| Luminance (cd/m2 ) | 350 |
| Backlight Life | 70,000 hr |
| Contrast Ratio | 1000:1 |
Touchscreen |
|
| Type | 5-wire analog resistive |
| Interface | USB/RS232 |
| Light Transmission | Above 75% |
| OS Support | Windows XP, Vista,7, 8, 10, 11, XPe and Linux |
| Surface Hardness | 4H |
Environment |
|
| Operating Temperature | -20 ~ 60 °C (-4 ~ 140 °F) |
| Storage Temperature | -30 ~ 70 °C (-22 ~ 158 °F) |
| Relative Humidity | Operating, 95% RH @ 40 °C, Non-Condensing Non-Operating, Operating, 95% RH @ 60 °C, Non-Condensing |
| IP Rating | IP-66 graded front panel |
| Vibration | 5 ~ 500 Hz, 1 Grms (Operating, Random) |
